32 differential channels simultaneous sampling,
0.2 mcV RMS noise on shorted channels at 512 SPS,
4xAD7771BCPZ 64 kSPS,
STM32H743ZIT6 MCU 1027 DMIPS,
isolated USB, UART, SPI,
SD-Card,
FreeEEG32 + alpha1.5 32 channels 5min eyes closed, https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/OpenVIBE/gdf...,
ciPLV 32 channel coherence onboard with Butterworth filtering, output via isolated USB, UART, SPI, and SD-Card https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/AC6/STM32H74...,
for multi-architecture amd64, arm64, armhf docker containers with OpenVIBE https://github.com/neuroidss/FreeEEG32-alpha1.5/blob/master/multiarch/op...
gerber: https://github.com/neuroidss/FreeEEG32-alpha1.5/raw/master/KiCAD/out/ger...
bom: https://docs.google.com/spreadsheets/d/1l08JTSrGSRcxZXpl6SzznG30cp7E945A...
